X1A0001410000是一款超小型FC-135R晶振MCU子時鐘諧振器，電子產業的推陳出新，使得我們能夠在偌大的市場中找到更加機會，同時也是挖掘出巨大的價值，愛普生公司在晶體行業擁有幾十年的專業經驗，并針對當下的市場做出一番調整，開發出性價比超高的晶振產品，推出了SMD晶振，F(xiàn)C-135R晶振，編碼X1A0001410000，尺寸(LxWxH)3.2 x 1.5 x 0.9 mm，客戶負載capacitance12.5pF，頻率公差+ / - -20.0 ppm，工作溫度-40至+85°C，額外OptionsNo，F(xiàn)requency32.768000kHz，這是一款貼片型的無源晶振，廣泛適用于消費設備。

Product Number	LxWxH	Model	Frequency	CL Value	Freq.tol. @+25°C	Oper. Temper. range
X1A0001410001	3.2 x 1.5 x 0.9 mm	FC-135R	32.768kHz	7 pF	+/-20.0 ppm	-40 to +85 °C
X1A0001410002	3.2 x 1.5 x 0.9 mm	FC-135R	32.768kHz	9 pF	+/-20.0 ppm	-40 to +85 °C
X1A0001410003	3.2 x 1.5 x 0.9 mm	FC-135R	32.768K晶振	12.5 pF	+/-20.0 ppm	-40 to +85 °C
X1A0001410004	3.2 x 1.5 x 0.9 mm	FC-135R	32.768kHz	9 pF	+/-10.0 ppm	-40 to +85 °C
X1A0001410005	3.2 x 1.5 x 0.9 mm	FC-135R	32.768kHz	12.5 pF	+/-10.0 ppm	-40 to +85 °C
X1A0001410006	3.2 x 1.5 x 0.9 mm	FC-135R	32.768kHz	6 pF	+/-20.0 ppm	-40 to +85 °C
X1A0001410011	3.2 x 1.5 x 0.9 mm	FC-135R	32.768kHz	7 pF	+/-10.0 ppm	-40 to +85 °C
X1A0001410015	3.2 x 1.5 x 0.9 mm	FC-135R	32.768kHz	6 pF	+/-15.0 ppm	-40 to +85 °C
X1A0001410016	3.2 x 1.5 x 0.9 mm	FC-135R	32.768kHz	6 pF	+/-10.0 ppm	-40 to +85 °C
X1A0001410019	3.2 x 1.5 x 0.9 mm	FC-135R	32.768kHz	12 pF	+/-10.0 ppm	-40 to +85 °C
X1A0001410022	3.2 x 1.5 x 0.9 mm	FC-135R	32.768kHz	18 pF	-20.0/+10.0 ppm	-40 to +85 °C
Q13MC1462000100	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	7 pF	+/-20.0 ppm	-40 to +85 °C
Q13MC1462000200	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	12.5 pF	+/-20.0 ppm	-40 to +85 °C
Q13MC1462000300	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	7 pF	+/-10.0 ppm	-40 to +85 °C
Q13MC1462000400	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	9 pF	+/-20.0 ppm	-40 to +85 °C
Q13MC1462000600	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	6 pF	+/-20.0 ppm	-40 to +85 °C
Q13MC1462000900	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	7 pF	+/-50.0 ppm	-40 to +85 °C
Q13MC1462001000	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	12.5 pF	+/-50.0 ppm	-40 to +85 °C
Q13MC1462001100	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	12 pF	+/-20.0 ppm	-40 to +85 °C
Q13MC1462001700	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	12.5 pF	+/-10.0 ppm	-40 to +85 °C
Q13MC1462003700	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	12.5 pF	+/-100.0 ppm	-40 to +85 °C
Q13MC1462005900	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	8 pF	+/-10.0 ppm	-40 to +85 °C
Q14MC1462001500	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	6 pF	+/-20.0 ppm	-40 to +85 °C
Q14MC1462001800	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	15 pF	+/-20.0 ppm	-40 to +85 °C
Q14MC1462002500	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	12.5 pF	+/-20.0 ppm	-40 to +85 °C
Q14MC1462002600	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	7 pF	+/-10.0 ppm	-40 to +85 °C
Q14MC1462003000	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	12.5 pF	+/-20.0 ppm	-40 to +85 °C
Q14MC1462003300	7 x 1.5 x 1.4 mm	MC-146	32.768kHz	9 pF	+/-20.0 ppm	-40 to +85 °C

FC-135R是愛普生廣泛采用的FC-135的低ESR (50 kΩ Max.)版本，32.768 kHz晶體單元，石英晶振。適用于從消費設備到工業設備應用的MCU子時鐘和模塊。對于擴展溫度范圍應用到+105°C。愛普生是khz波段晶體單元的領先供應商，并提供一系列內置振蕩器,除了晶體之外，振蕩器電路集成電路和內置實時時鐘集成電路的實時時鐘模塊單位。
